Transport conveyor VB

The transport conveyor is designed for conveying. This type is the transport belt to convey products vertically. On demand, the belt can be made of PVC or PU.

Product Information

This transport conveyor is designed for conveying. This type is the transport conveyor to convey products vertically. On demand, the belt can be made of PVC or PU. It is available in opening sizes of 11 and 16 cm to suit various diameter products.

An extra motor can be included on demand to ensure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors. An on demand, frequency inverter can be added to control the speed of the belt.

The Frame can be made on demand from zinc plated steel, stainless steel, and painted mild steel.

Characteristics

  • Used to convey product vertically
  • The belt can be made of PVC or PU
  • A frequency inverter can be added on demand
  • An extra motor can be included on demand
  • Various length and width options are available to suit your design requirements
  • Belts can be supplied with various cleat options like fingers, THW and THW interrupted
  • Available in opening sizes of 11 and 16 cm to suit various diameter products.

Specifications

VRE 80 VRE 100 VRE 120 VRE 160 VRE 240
Width of the machine (cm) 80 100 120 160 240
Length of the machine (cm) 150 t/m 600, steps of 25 cm 150 t/m 600, steps of 25 cm 150 t/m 600, steps of 25 cm 150 t/m 600, steps of 25 cm 150 t/m 600, steps of 25 cm
Opening size of the vertical belt (cm) 11, 16 11, 16 11, 16 11, 16 11, 16

Options

  • Material and treatment (frame)
Zinc plated steel
Frame is made from zinc plated steel. The bearings and drive/idle rollers are from mild steel
Stainless steel
Frame is made from stainless steel. The bearings and drive/idle rollers are from mild steel
Painted mild steel
Frame is made from painted mild steel. The bearings and drive/idle rollers are from mild steel
  • Belt
PVC
The belt is made of PVC
PU
The belt is made of PU
  • Cleats
Fingers
THW

THW interrupted

  • Electrical control
No electric
Motors only. Wiring, additional sensors and/or control panel are not included
Stand-alone
Motors, necessary sensors, switch box and control box
Central control in line
Motors and necessary sensors
  • Frequency inverter
Speed adjustment
A frequency inverter is included to control the speed
  • Material and treatment (electrical panel)
Painted mild steel
The electrical panel is made from painted mild steel
Stainless steel
The electrical panel is made from stainless steel
  • Legs
Amount of legs
Amount of legs depends on the design of belt
  • Switch
Maintenance
A maintenance switch is included
Reverse
A reverse switch is included
Start/stop
A start/stop switch is included
  • Product sensor
Sensor
A product sensor is included
  • Bracket
Bracket
There is a bracket included
  • Extra motor
0.37 kW
An extra 0.37 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
0.75 kW
An extra 0.75 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
1.1 kW
An extra 1.1 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
1.5 kW
An extra 1.5 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
2.2 kW
An extra 2.2 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
3 kW
An extra 3 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
