Transport conveyor TCC
The transport conveyor is designed for conveying. This type of transport belt has high side panels and cleats. On demand, the belt can be made of PVC or PU.
The transport conveyor is designed for conveying. This type of transport belt has cleats. On demand, the belt can be made of PVC or PU. Belts can be supplied with straight and staggered cleats. The height of the cleats is 40 mm.
On demand, a cover is mounted on the top and bottom of the machine. This cover can be made from zinc plated steel or stainless steel. On demand, a frequency inverter is included to control the speed.
Characteristics
- Available in 20, 40, 60, 80, 100 and 120 cm width
- Belt available in 100 – 2500 in steps of 25 cm
- On demand, cleats can be straight or staggered
- On demand, the topside cover and bottom side cover can be made from zinc plated steel or stainless steel
- On demand, a frequency inverter is included to control the speed
- Available in various options like zinc plated steel, stainless steel, and painted mild steel
Specifications
| TCC 20 | TCC 40 | TCC 60 | TCC 80 | TCC 100 | TCC 120 | |
|---|---|---|---|---|---|---|
| Width of the machine (cm) | 20 | 40 | 60 | 80 | 100 | 120 |
| Length of the machine (cm) | 100 t/m 1200, steps of 25 cm | 100 t/m 1200, steps of 25 cm | 100 t/m 1200, steps of 25 cm | 100 t/m 1200, steps of 25 cm | 100 t/m 1200, steps of 25 cm | 100 t/m 1200, steps of 25 cm |
Options
- Material and treatment (frame)
Zinc plated steel
Frame is made from zinc plated steel. The bearings and drive/idle rollers are from mild steel
Stainless steel
Frame is made from stainless steel. The bearings and drive/idle rollers are from mild steel
Painted mild steel
Frame is made from painted mild steel. The bearings and drive/idle rollers are from mild steel
- Belt
PVC
The belt is made of PVC
PU
The belt is made of PU
- Cleats
Straight
The type of cleats is straight
Staggered
The type of cleats is staggered
- Cleats height
40
The height of the cleats is 40 mm
- Electrical control
No electric
Motors only. Wiring, additional sensors and/or control panel are not included
Stand-alone
Motors, necessary sensors, switch box and control box
Central control in line
Motors and necessary sensors
- Frequency inverter
Speed adjustment
A frequency inverter is included to control the speed
- Material and treatment (electrical panel)
Painted mild steel
The electrical panel is made from painted mild steel
Stainless steel
The electrical panel is made from stainless steel
- Material and treatment (bottomside cover)
Zinc plated steel
A cover is mounted on the bottom of the machine, made from zinc plated steel
Stainless steel
A cover is mounted on the bottom of the machine, made from stainless steel
Length of bottomside cover
0 t/m 1200, steps of 25 cm
- Material and treatment (topside cover)
Zinc plated steel
A cover is mounted on top of the machine, made from zinc plated steel
Stainless steel
A cover is mounted on top of the machine, made from stainless steel
Length of topside cover
0 t/m 1200, steps of 25 cm
- Switch
Maintenance
A maintenance switch is included
Reverse
A reverse switch is included
Start/stop
A start/stop switch is included
- Product sensor
Sensor
A product sensor is included
- Bracket
Bracket
There is a bracket included
- Extra motor
0.37 kW
An extra 0.37 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
0.75 kW
An extra 0.75 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
1.1 kW
An extra 1.1 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
1.5 kW
An extra 1.5 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
2.2 kW
An extra 2.2 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
3 kW
An extra 3 kW motor is included to make sure the belt can move both ways. If this option is selected, the originally selected power (kW) must be divided between the two motors
