Allround Vegetable Processing manufactures a range of vegetable destoners that effectively remove stones, clods, high-density material, and debris from produce prior to the washing process. Removing stones from produce at the start of the handling process helps prevent damage to produce or equipment caused by stones present throughout the washing and processing line.
Allround standard destoner comes in a painted mild steel frame with bearings and drive/idle rollers are made of mild steel. However, on demand, it can supplied in stainless steel AISI304, but bearings and drive/idle rollers are of mild steel.
Allround standard destoner comes with an 8 mm spacing rubber coated mild steel 50 mm cleat height product conveyor and a 10 mm spacing mild steel 40 mm cleat height stone conveyor. However, on demand, it can supplied in stainless steel.
If required, the destoner can be on a subframe to accommodate height difference. The subframe can be made from painted mild steel, stainless steel AISI304, and galvanized steel. The height of the subframe can varies from 0-3 meters.
Characteristics
- Models are available in 110, 150, and 200 cm width
- Effective removal of stones prior to washing
- Gentle and compact machine
- On demand, spray tube can be integrated into the produce conveyor to further clean produce
- Water management can be done manually or automatically with valves and level meters
- 8 mm spaced and 50 mm cleat height rubber coated product conveyor in mild steel or stainless steel
- 10 mm spaced and 40 mm cleat height stone conveyor in stainless steel or mild steel
Specifications
| D 110 | D 150 | D 200 | |
|---|---|---|---|
| Width of the tank inlet (in cm) | 110 | 150 | 200 |
Options
- Material and treatment (frame)
- Material and treatment (product conveyor)
The cleats height is 50 mm
The gap size is 8 mm
The cleats height is 50 mm
The gap size is 8 mm
- Material and treatment (stone conveyor)
The cleats height is 40 mm
The gap size is 10 mm
The cleats height is 40 mm
The gap size is 10 mm
- Electrical control
- Material and treatment (electrical panel)
- Water management
- Cleaning
- Material and treatment (subframe)
- Height of subframe
