The box fillers are designed to fill boxes of various sizes in the most product friendly way possible. The machines are designed in such a way that the fall height is reduced as much as possible. When boxes are removed in time, the machine is capable of filling without interruptions. The vertical belts are lowered in the box, and fill layer by layer. In this setup, the drop height is reduced to an absolute minimum. This vertical box filler is also suitable for big-bags.
Specifications
| Length of the horizontal belt (cm) | 275, 350 |
| Maximum length of the box (cm) | 180 |
| Maximum width of the box (cm) | 240 |
| Height of the vertical belt (cm) | 200 |
| Width of the belt (cm) | 70 |
| Opening size of the vertical belt (cm) | 11, 16 |
Options
Material and treatment (frame)
- Painted mild steelFrame is made from painted mild steel
- GalvanizedFrame is made from galvanized steel
- Stainless steelFrame is made from stainless steel
Cleats
- FingersFinger cleats are added to carry the produce
- THWThe THW cleats are reinforced and therefore have a high wear resistance
- THW interruptedThe THW interrupted cleats are reinforced and therefore have a high wear resistance
Electrical control
- No electricMotors only. Wiring, additional sensors and/or control panel are not included
- Stand-aloneMotors, necessary sensors, switch box and control box
Material and treatment (electrical panel)
- Painted mild steelThe electrical panel is made from painted mild steel
- Stainless steelThe electrical panel is made from stainless steel
Weighing unit
- The weighing unit is to weigh the big bags and to stop filling the big bag when the desired weight is reached
