Potato dryer2018-08-27T08:52:15+00:00

Project Description






Potato dryer

Categorie: Drying

The Allround Potato dryer is designed to dry potatoes after washing. This is done by felt rollers. These felt rollers absorb water that comes with the potatoes after washing. In their turn, these felt rollers are wringed out by stainless steel rollers.

The machine is equiped with stainless steel plates, to ensure durability of the machine.

Types and Specifications

Allround Potato Air dryer

DR 60-10

Total width machine ?? mm
Length of rollers 600 mm
Number of rollers 10
Drawing
Allround Potato Air dryer

DR 100-12

Total width machine ?? mm
Length of rollers 1000 mm
Number of rollers 12
Drawing
Allround Potato Air dryer

DR 140-17

Total width machine 1940 mm
Length of rollers 1400 mm
Number of rollers 17
Drawing

Options

By-pass

In an Allround VP integrated line, not all products are to be dried. For this reason, Allround VP can equip the machine with a by-pass belt which is mounted on the frame of the machine. In this case, the machine is equipped with wheels to make sure the switch between drying and not drying the produce can take place rapidly.

Estimated capacity
(tons/hour)

DR 60-10 DR 100-12 Dr 140-17
Potatoes  6  10 20
